The Roland System 100M |
|
| The Roland System 100m | |
 |
 |
| A 190 rack system in use at the old Point Source Studio |
A Roland 100m 191J cabinet with 2 x 172, 1 x 131 and 2 x 182 |
 |
|
| The rear of a 191 rack showing the power and CV bus connections | |
The Modules |
|
| Number | Description |
| 110 | VCO, VCF, VCA |
| 112 | Dual VCO |
| 121 | Dual VCF |
| 130 | Dual VCA |
| 131 | Output Mixer |
| 132 | Dual Mixer and Voltage Source |
| 140 | Dual Envelopes and LFO |
| 150 | Ring Mod, Noise, S+H, LFO |
| 172 | Phase Shifter, Audio Delay and Gate Delay |
| 182 | Analog Sequencer |
| More info and service notes: | Music Machines |
